Information
- 3.5" 640x480 display resolution IPS LCD. HD LCD.
- Same display size as the original screen.
- Wide View angle up to 178 degree.
- Built-in OSD menu.
- Retro pixel Effects: Normal, Retro pixel, Scanline 1 and Scanline 2.
- High brightness, 15 brightness levels.
- 8 color modes.
- Touch Screen to change the Retro pixel.
- Image position adjustable. No worry to aligning the LCD screen.
- 720P HDMI-Compatible Output. Support to play games on TV Set.
- Built in 3 TV Aspect Ratio.
- FPC connect cable design. Simpler wiring and easier installation.
Package Includes
1xBacklight LCD.
1x HDMI version PCB.
1x FPC connect cables.
1xDouble-sided tape.
5x 10pF capacitors.
2x 200Ohm resistor
Several Red wires.
1x Glass screen lens.
1x HDMI adapter cable,
NOTE
There are two version LCD MOD kit in this advertising listing. 'Without HDMI version' and 'HDMI version'.
- The 'without HDMI version' doesn't require trimming the shell.
- The 'HDMI version' requires trimming the shell.
- Support Sega single chip motherboard and dual chip motherboard:
--Single chip motherboard:1 ASIC PCB revisions 837-9130 / 837-9024 / 837- 8560
--Dualchip motherboard:2 ASIC PCB revisions 837-7996 / 837-7719-01 VA0/837-7398-03
- NOTE1: Doesn't supported: Majesco Game Gear VA4 / VA5
- NOTE2: The motherboard with the "MADE IN TAIWAN" logo on the motherboard of the game console does not support.
Information
- Same display size as the original screen.
- Wide View angle up to 178 degree.
- Built-in OSD menu.
- High brightness, 15 brightness levels. 8 color modes.
- Retro pixel Effects: Normal, Retro pixel, Scanline 1 and Scanline 2.
- FPC connect cable design. Simpler wiring and easier installation.
Package Includes
1xBacklight LCD.
1x Without HDMI version PCB.
1x FPC connect cables.
1xDouble-sided tape.
5x 10pF capacitors.
2x 200Ohm resistor
Several Red wires.
1x Glass screen lens.
OSD Menu Operation
-Press the START+1+2 buttons for 1 second to activate the OSD Menu.
-Press the 'START' button to select the adjustment item when OSD Menu activated.
-Press the '1' or '2' button to adjust the item when OSD Menu activated.
For Sega NOMAD LCD IPS Screen Replacement
Information
- 3.5" 640x480 display resolution IPS LCD. HD LCD.
- Same display size as the original screen.
- Wide View angle up to 178 degree.
- Built-in OSD Menu.
- Retro pixel Effects: Normal, Retro pixel, Scanline 1 and Scanline 2.
- High brightness, 15 brightness levels.
- 8 color modes.
- Touch Screen to change the Retro pixel.
- Touch function' ON/OFF in the OSD menu.
OSD Menu Operation
-Press the MODE+A+B buttons for 1 second to activate the OSD Menu.
-Press the MODE button to select the adjustment item when OSD Menu activated.
-Press the A or B button to adjust the item when OSD Menu activated.
Packing including
1x IPS LCD
1X RGB PCB board
1x Double-sided tape
1x Glass lens, Several red wires.
For Sega LCD Replacements
Compatible with GG, SMS & SG-1000 games
Screen Information
- 3.5-inch a-Si TFT LCD liquid crystal screen
- 320*240 resolution, point-to-point full-screen display, high refresh rate, bright colors
Support Sega single chip motherboard and dual chip motherboard.
- --Single chip motherboard:1 ASIC PCB revisions 837-9130 / 837-9024 / 837- 8560
- Dualchip motherboard:2 ASIC PCB revisions 837-7996 / 837-7719-01 VA0/837-7398-03
NOTE
⚠All pacakages are sent without the paper manual. We have the online manual to you.
⚠Don't support Majesco Game Gear VA4 / VA5.
⚠The mainboard with the "MADE IN TAIWAN" game console can not work with these LCD kits.
⚠ Some SEGA housing have a metallic coating on the inside. The metallic coating on the plastic was conductive. It causes the color modes/Aspect modes to cycle automatically. Please scrape off the metallic coating and put the touch direct on plastic.
Technical Information
1. One chip design. More environmentally friendly. More power-saving.
2. Built-in SDRAM cache in the Chip.
3. FPC connect cable design. Simpler wiring and easier installation.
4. Adjust brightness via the thumbwheel.
5. 8 color modes. 3 Image Aspect Ratio. Scanline.
6. 3 Image Aspect Ratio. Small, Normal, Enlarge.
Note: the 'Enlarge Aspect Ratio'not full screen.7. Support VGA output. (Doesn't include the VGA connector)
Operation Buttons
Press 'START+1+2' to turn VGA output on or off.
Touch the 'left touchpad' to change the color modes.
Touch and hold the 'left touchpad' 3 seconds to turn 'scan line' on or off.
Touch and hold the 'right touchpad' and 'left touchpad' 3 seconds to change the image aspect.
Package inclues
- 1x Backlight LCD.
- 1x PCB.
- Double-sided tape.
- 5x 10pF capacitors.
- 2x 200Ohm resistor
Others
DreamPSU
Conductive Pad
Conductive Pad
Conductive Pad
Conductive Pad
Conductive Pad
Adapter
Conductive Pad
Glass Len
Glass Len
Glass Len
AV Cable
Plastic Spares
