SNES RGB Amp with CSync (THS7374) mod kit
- It is suitable mostly for 1CHIP-03 and SNES Mini / SFC Jr. boards.
- It can also be installed on 1CHIP 01/02 boards, but you need to make sure that pin 3 on the multi out is disconnected, or the board can be damaged.
Features
- The THS7374 is the latest SDTV Amplifier IC from Texas Instruments.
- Low pass filter option (enabled by default). Can be disabled by soldering the J1 jumper.
- Integrates brightness fix for 1CHIP consoles. Please choose your 1Chip console from the dropdown, in order to populate the resistors with the correct values.
Installation Instructions
- For SNES Mini or SFC Jr.
- For Regular SNES 1CHIP-03
- It is only a SNES RGB PCB Board.
You need buy a customised RGB cable to let it work. The normal RGB cable will not work.
Please make sure you get the right RGB cable before the installation.
