HDMI Port
PCB Board
Manual of TV Convert GBA SP Kits
Step 1
Cut the shell as the picture
Step 2
Paste the double-sided tape on the back of the HDMI PCB board.
Step 3
Paste the HDMI PCB board on the metal shell of the LCD screen.
And, soldering 2 wires on the SO1,SO2.
Step 4
Plug the FPC cable in.
Step 5
Plug the FPC cable in.
Step 6
Plug the V2 board FPC cable in.
Step 7
Put kits in the shell.
Step 8
Soldering 2 wires from SO1, SO2 f the HDMI PCB board
to SO1SO2 ofthe GBA SP motherboard board
Done
Start to play your console.
